Community Created Accessories

PreviousCommunity Projects NextCommunity Shared Analyzers

Last updated 5 months ago

Several Logic accessories have been made available by our community of users. These are listed below. If you've created an accessory that you'd like to share, let us know!

10:1 Attenuator

Product Page: http://www.hunterembedded.co.uk/products/
Description: The attenuator plugs in between the Logic device and the probes and is shaped to allow multiple ones to be used together. It provides attenuation with Low Frequency compensation on 4 channels.

Logic Pro 16 Analyzer Dock Station

by earlynerd
Thingiverse Download: https://www.thingiverse.com/thing:3112823

Logic Holder

by PCBGRIP
Thingiverse Download: https://www.thingiverse.com/thing:735911

Logic Pro 16 Desktop Organizer

by BuildXYZ
Thingiverse Download: https://www.thingiverse.com/thing:3473347

Saleae Tower-of-Hanoi Organizer

by Helmut Lord
Printables Download: https://www.printables.com/model/860963-saleae-tower-of-hanoi-organizer

Tigard Saleae Stripe

by Cut Trace
Available Here: https://www.tindie.com/products/cuttrace/tigard-saleae-stripe/
